    Retro Feature: The Making and the history of the Nintendo Game Boy



    This unassuming little brick would go on to change the way we play games forever



    Last year the machine turned 20, but what was it like to work with? We speak to the developers who made this legendary handheld sing
    Every now and then a product comes along that is so groundbreaking that it becomes synonymous with its function. The Hoover, Cellotape, Pritt-Stik…these names and many more like them have become so intrinsically linked with their purpose that people often fail to realise that they’re a brand, rather than a description of the object. Another example is the Nintendo Game Boy; for more than a decade this moniker became so tied to the pastime of portable gaming that it was only usurped when Nintendo released an even more successful console in the shape of the Nintendo DS.
    The History

    The origins of this seminal console can be traced back to one of Nintendo’s early portable successes – the Game & Watch range. Created by assembly line engineer turned design guru Gunpei Yokoi and his highly talented team at Nintendo Research and Development 1, the line of LCD handheld games showcased basic technology but utilised it in innovative ways, ensuring mass appeal and gaining its manufacturer mountains of cash in the process.




    With Tetris, the Game Boy story may have been very different

    Yokoi concocted the idea of ‘Lateral Thinking of Withered Technology’; a design philosophy which focused on using inexpensive and familiar components in new and interesting ways. This model would carry through to Yokoi’s next project, which would make the success enjoyed by the Game & Watch series look almost inconsequential by comparison.
    By the time the ‘80s were drawing to a close Nintendo’s standing in the video game industry was impressive; the NES had single-handedly saved the world console market from extinction following the cataclysmic crash of ’83 and the aforementioned Game & Watch range was still shifting a highly respectable number of units. However, Yokoi knew that the technology behind these LCD games was starting to look outdated when placed alongside the experiences offered by the NES and other 8-bit home computers, so he began his quest to create a successor.


    As was the case with the Game & Watch, this new machine wouldn’t use revolutionary features to get itself noticed. Yokoi’s design beliefs were too strong; he knew that if he tried to create a console that was at the cutting edge of technology, it would be expensive and therefore lack mass market appeal. Instead he looked at building a device that was economical to manufacture and perfectly suited for its purpose – mobility.




    This surprisingly matrue UK advert shows that Nintendo was after a very different market to that which had made the NES such a success

    This new console was shown in prototype form in 1987 and would later be demoed at various trade shows. The effect it had on the development community was electrifying. “It was really pretty amazing and exactly what we needed,” says Rare’s Paul Machacek, who coded the fantastic Game Boy title Donkey Kong Land and still works within the firm as a Program Manager. “We had expectations about a handheld gaming system when Rare founder Tim Stamper went to Consumer Electronics Show in the US, but he returned with news about a completely different handheld gaming system. This was in the days before the Internet and you couldn’t just pick up the latest photos and news from the show floor on websites like today. I can’t remember whether we had to wait for a monthly magazine or got something shipped from Japan, but the first time I saw a Game Boy I just thought it looked like a little arcade cabinet in your pocket.”


    This new machine inherited one vitally important design aspect from its ancestor the Game & Watch – an 8-way digital pad, or ‘D-Pad’ as it’s more commonly known as. We take this interface for granted now but it was Yokoi and his team at R&D1 that developed the concept: sensing that joysticks would impinge on a handheld’s mobility, Yokoi concocted the D-pad – a flat controller that wouldn’t protrude from the casing of any handheld it was applied to. The concept also found its way onto the NES, where it was equally successful. The NES in turn influenced other aspects of the Game Boy interface – the familiar A and B buttons were present, along with the ‘Select’ and ‘Start’. This shared control method was beneficial in two ways: it allowed NES owners (and there were plenty of them) to effortlessly pick up and play this shiny new portable, and it also made it easy to port popular NES franchises to the machine.




    Early television ads focused on the machine's biggest selling point - its portability



    As the Japanese release date approached, Nintendo confessed that it had high hopes for the device; President Hiroshi Yamauchi confidently predicted that it would sell over 25 million in the first three years – quite a bold claim for the time. There might have been quite a few people that scoffed at such optimism, but when the machine effortlessly sold 300,000 units in its first day on sale in Japan in 1989, such scepticism seemed foolishly misplaced. It was obvious that Nintendo – and Yokoi – had struck gold once again.


    Software played a massive role in this victory and no game is more significant in shaping the Game Boy’s history than the ultra-addictive puzzle title Tetris, created by Russian programmer Alexei Pajitnov. Although this legendary title was already widely available on PC at the time, its appearance on the Game Boy is arguably the reason it is remembered so fondly today. Nintendo of America's CEO Minoru Arakawa witnessed a demonstration of the puzzler at a trade show in 1988 and moved quickly to ensure that Tetris would become the Game Boy’s first ‘killer app’. It was included as a pack-in title in every region except Japan and would become instrumental in cementing the console’s reputation as a ‘must-have’ gadget in the US, where the initial shipment of one million consoles sold out within a matter of weeks.




    The Game Boy witnessed a flood of software, including some noted arcade covnersions - even though the hardware arguably wasn't up the task of replicating the experience



    As was the case with the Game & Watch the Game Boy used LCD technology, but instead of static images it boasted a ‘dot-matrix’ screen and could therefore display 160 by 144 individual pixels. It was monochrome, lacked lighting and could only display four different shades of grey, but it is unquestionably one of the reasons why the console was such an enormous success.


    It meant that the machine was incredibly energy efficient by the standards of the time, and although it’s rumoured that several of Nintendo’s executives put pressure on Yokoi to adopt a more visually impressive colour screen, his approach was ultimately vindicated when rival manufacturers released their full-colour, backlit portable machines onto the market shortly after Nintendo’s handheld launched. Their battery life was dismal and this factor undoubtedly helped the Game Boy win the war. ”Kids hate replacing batteries; it requires having to ask your parents for something,” chuckles Dylan Cuthbert, former Argonaut employee and Managing Director of Q-Games. “The longer a machine can run, the more people enjoy themselves and want to play more games on it.”




    The Game Boy Color - along with Pokémon - helped bring the aging technology to a fresh new market



    However, while it was easy on power consumption the screen wasn’t universally adored by everyone and even at the time there were rumblings of discontent over its blurriness. Fast-moving objects were incredibly hard to see, which made some games difficult to play. “You didn’t want lots of the screen to have a lot of detail that was moving continuously,” explains Rare’s Chris Sutherland. “It meant keeping the backgrounds plainer or ensuring there were pauses in the scrolling. Objects like bullets had to be made larger, or with significant outlines so that players could more easily spot them.”


    This problem was amplified by the fact that the screen functioned best when viewed in direct light; to tackle this problem a wide variety of bolt-on peripherals were developers that not only added light sources but also magnified the display. The usefulness of such devices was questionable at best; when installed they rendered the Game Boy distinctly un-portable.
    More software followed, with early hits such as Super Mario Land, Castlevania II: Belmont’s Revenge and Operation C helped to keep interest in the console high. Just had been the case with the 8-bit NES, the Game Boy enjoyed a superlative degree of third-party support with all of the big names in the industry backing the console with their software: Konami, Square, Capcom, Irem and Hudson – as well as plenty of other publishers and developers – all pledged to support Nintendo. This resulted in an avalanche of software and made it very hard for rivals like Atari and Sega to gain a foothold, despite their more technically powerful Lynx and Game Gear hardware.




    Even the Gulf War couldn't stop this Game Boy unit from functioning

    As the years rolled by the popularity of the Game Boy remained buoyant, while rival handhelds fell by the wayside. This success was no doubt assisted by quality games such as The Legend of Zelda: Link’s Awakening, Super Mario Land II, Donkey Kong Land and Metroid II: Return of Samus. However, it was the Japanese release of the first Pokémon title in 1996 that catapulted the Game Boy into hitherto uncharted realms of commercial triumph.


    Sadly this second wind was something of a double-edged sword for the monochrome marvel. It resulted in Nintendo looking into successors for the ageing hardware (although without Yokoi’s help – he had left the firm in disgrace after the failure of the Virtual Boy and would later meet a tragic end in a road traffic accident), and the first baby steps were made with the Game Boy Pocket in the same year that Pokémon made its Japanese debut.


    Essentially a scaled-down version of the machine that boasted a sharper screen and ran on two AAA batteries, the Game Boy Pocket revitalised hardware sales and was a much-needed aesthetic update that kept the console relevant in the increasingly fashion-conscious PlayStation era. However, another upgrade wasn’t far off and this time Nintendo would enhance the concept far more convincingly – the Game Boy Color delivered the bright and attractive visuals that fans had been clamouring for since the early ‘90s and although the machine was based heavily on the existing Game Boy tech (it was even backwards compatible with existing black & white software) it essentially marked the end for the original ‘breeze-block’ version of the machine. As the Color variant gained popularity, over 50 million of its monochrome siblings were relegated to the back of drawers and cupboards the world over.




    The Japan-only Game Boy light solved the issue of having to play under a lamp

    A Developer’s Viewpoint

    Given the massive popularity of the Game Boy, finding programmers with experience of creating software for the machine is like shooting ducks in a barrel. “I first encountered the Game Boy the first day I started working at Rare back in mid-1989, and it hadn’t even been released then, so it was definitely a surprise,” recalls Sutherland. “Although the original looks a bit bulky nowadays, back then it seemed impressively compact.”


    However, in those early days, coding for the Game Boy wasn’t exactly a walk in the park. “Part of the challenge in developing for Game Boy was that there was limited documentation; it was usually some very basic hardware information that was translated from the Japanese,” continues Sutherland. Thankfully the CPU that powered the portable was at least known to programmers. “At the Game Boy’s heart was a castrated Z80, a CPU I was very familiar with from the Spectrum and Amstrad CPC,” explains Jon Ritman, the legendary coder behind Head Over Heels and the superlative Monster Max on the Game Boy. “They had taken out a few useful features such as the 16-bit instructions and they had also removed most of the registers. The memory was paged in and out to give you access to a lot of memory – far more than a Spectrum could address – but the paging could be hard to manage. However, it was great that it had far more memory than I was used to.”




    Rare's Donkey Kong Land would replicate the same success enjoyed by its SNES-based sibling, Donkey Kong Country



    Explaining the inner workings of any games machine in lay terms is tricky, but Rare’s Machacek is happy to run through the basics. “It boasted very simple screen architecture with a single character mapped screen that you could scroll,” he says. “A small bank of characters for background, a similar size bank for sprites and a third similar size bank shared between background and sprites. We were always fighting with that one because it was a juggling act between optimising the background enough to free up space to include the sprites you needed. Just to get this juggling in perspective, if each unique character available in both of those banks for the backgrounds were only displayed once on screen, you’d only fill a quarter of the visible screen space. Just like the NES, you really had to use a lot of repeated characters to fill the background. If you were doing a big long scrolling level with lots of unique scenery then massive amounts of downloading to the banks had to take place.”


    Many programmers found that working on the Game Boy was preferable to coding for other popular platforms, including its domestic brother, the NES. “I learned to program on a 6502 processor system, rapidly switching to Z80 ones before joining Rare in 1988,” remembers Machacek. “Working initially on the NES brought me back to 6502 but the Game Boy allowed me to return to Z80 which I preferred. In some ways the Game Boy seemed a step up from other systems I had used; the Amstrad CPC 464 had no sprites and the ZX Spectrum, which I love to bits, had attribute problems. Aside from the lack of colour, it was a very similar format to the NES that we were already working with.”


    How very true...



    In fact, the machine’s 4-shade greyscale screen was seen as a bonus by some programmers. “I had been making games for the Spectrum that were using the screen as just two colours, so monochrome didn't phase me at all,” comments Ritman. “Four shades was heaven for me – it was two more than I had been using on the Spectrum!” Over time various tricks were developed in order to work around the shortcomings of the display. “We were very clear that sprites needed to stand out clearly from backgrounds, and the backgrounds would blur a bit when you scrolled quickly due to the lag on the display,” says Machacek. ”Efforts were made to give important sprites, like the player character, strong outlines to help delineate them from the rest though.”
    On the audio side of things the Game Boy offered an additional challenge for coders. “The sound chip was interesting,” comments Cuthbert. “It had a ‘user wave table’ of something daft like 20 entries, each of which was 4-bit, so if you could refresh it quickly enough it could play sampled sounds, albeit very low-res samples. It also had a more regular FM-style chip and a noise generator.”


    Getting the most out of this humble setup was no easy task. “The engineers at Rare dabbled with the basic sound effects that our own wave-based audio system could supply,” recalls Machacek. “Most of the engineers at Rare didn’t understand it that well; I think Mark Betteridge (now studio head of the company) was the only one of us that really knew how to get the sound he wanted. Later on we did incorporate some sound sampling into some titles and were able to play back low quality sampled audio for specific purposes.”


    ...and not so true.



    When coding for the Game Boy, many developers found that its similarity with the NES was immensely beneficial. “It was obviously a little less powerful, but many tricks we used on the NES translated well,” recalls Machacek. “Having pseudo-scrolling screens by using a repeating character pattern in places and downloading a repeating ‘texture’ to them that appeared to scroll was often seen. We always crammed in lots of carefully timed parallax scrolling effects as well. Access to the video RAM was limited, and the space for characters and sprites was small, so you constantly had to download artwork to the video RAM but could only do a little bit per frame. Trying to super-optimise your download code so that it wasted no time and shifted as much data as possible really paid off. I think, between judicious use of H-Blank as well as V-Blank downloading I managed to shift about 24 characters per frame which allowed us to do the sort of animations that appeared in Donkey Kong Land in 1995.”


    Based on the groundbreaking CGI-rendered SNES hit Donkey Kong Country, this highly enjoyable platformer is arguably the title that pushed the original Game Boy to its absolute limits, and Machacek is proud of what he achieved. “I deliberately sat down and spent three weeks doing nothing but engine work to get it to a point that it could handle anything we threw at it,” he remembers. “At that time many games were downloading about 6-8 characters a frame to the video bank and Donkey Kong Land needed much more than that with all of the rendered artwork it had to drive. I do know that my lead artist got fed up of waiting for me to finish this work! It was techy stuff that was invisible to him, and you have to understand that three weeks to write an engine seemed like an age when we had put out the Game Boy version of WWF SuperStars in three months flat – including testing – a couple of years earlier. But the Donkey Kong Land engine was able to shift 24 characters a frame by the end, and suddenly we were able to drive a lot of rendered artwork. I don’t think anyone complained after that, especially when it sold four million units!”




    Despite the rather questionable magazine ads, Donkey Kong Land's visuals were a real breakthrough for the humble monochrome format



    Having played an integral part in the success of this near-legendary console by coding some of its most memorable titles, it seems almost churlish to ask them what made the Game Boy so popular, but we’ll do it anyway. “In the 1980’s there were plenty of dedicated handheld, battery powered gaming machines,” says Machacek. “You’d buy a Space Invaders handheld, or a Pac-Man one, or whatever. Here we had a single device that you could buy lots of games for and carry them all around simply. It was far superior to those other machines in every way and even came with multiplayer capability if you had a cable. Traditional gamers were now on the move. But at the same time, that perfect marriage of Tetris and the Game Boy found a new audience that weren’t necessarily into games, and didn’t even realise probably that you could buy more games, but simply bought the ‘toy that plays that funny little blocks game’ that their friends had. Unlike home computers and consoles, the Game Boy could be taken to school or offices and combined with the low price, this was enough for non-gamers to get sucked in too.”


    The legacy of the Game Boy is considerable and some insist that Yokoi’s design ideals continue to influence Nintendo’s thinking even today. “Arguably Yokoi’s philosophy has continued with the Wii,” states Sutherland. “The lower spec and price point meant it has a larger initial potential audience, although remember the games are always what actually drive the sales – that’s why people buy it, not because of the hardware. Tetris was to Game Boy what Wii Sports is to Wii.”


    This feature originally appeared in its entirety in Imagine Publishing’s Retro Gamer magazine, and is reproduced here with kind permission.
